Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm

Product Categories
Top Fencing Co.Limited
Contact Now

Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm

Brand Name : TopClearvuFence

Model Number : 358 high security fence

Certification : ISO

Place of Origin : China

MOQ : 100 pcs

Price : 1USD -200USD

Payment Terms : L/C, L/C, T/T, Western Union, MoneyGram

Supply Ability : 1000 pcs per week

Delivery Time : 15 days

Packaging Details : Metal Frame Pallet

Materials : Q235 Steel

Mesh Opening : 3" x 0.5" x 8gague wire,12.70mm x 76.20mm

Diameter : 4.00mm ,3.00mm

Size : Available Customized

Color : All RAL color card

Treatment : Hot Dipped Galvanized Or Powder Coated

V Beams : Available

Sample : Free but pay freight cost

Accessoires : Clamp,Post ,Y arm for barb wire

Feature : Anti ,Resistant ,Cut ,Climb

Main Market : Africa ,Oceania ,Aisa

Salt Spray Test : Pass

Contact Now

358 mesh fencing also called anti climb fencing , prison mesh fencing . 358 mesh is applicated widely in prison,ministry of defence, Industrial sites, ball court and etc. ’358′ comes from the measurements, 3″ × 0.5″ × 8 gauge, samll apertures 76.2mm × 12.7mm is not possible for any intruder to get a foot hold for climbing, or indeed for getting any cutting tool into. High standard finish (42 micron hot dipped galvanized or powder coated to BS EN 13438) can ensure that 358 mesh is durably used in various of environment.
"358" comes from its measurements 3"*0.5"*8" gauges which equates to approx.76.2mm*12.7mm*4mm(Length*Height*Diameter) in metric.
358 security fences are extremely difficult to penetrate.with the small mesh aperture being effectively finger proof,and extremely
difficult to attack using conventional hand tools.
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm
Detailed Images
358 security fence specification as follow:
Wire thickness
3.0mm,4.0mm,5.0mm
Hole size
76.2*12.7mm
Width

2000mm,2200mm,2500mm
Height
1000mm,1200mm,1500mm,1800mm,2000mm
Post height
1400mm,1600mm,2000mm,23000mm,2500mm
Post type
square fence post 60*60*2.0/2.5mm,80*80*2.5/3.0mm
Fitting

Flat bar,metal clips
Surface treatment
electric galvanized/hot dipped galvanized then powder coated,hot dipped galvanized
358 security fence wire thickness:3.0mm,4.0mm,5.0mm
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm
358 security fence hole size:76.2*12.7mm
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm
358 security fence production process:
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm
Packing&Shipping
358 security fence packed in bulk,wooden pallet,metal pallet
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm
Wire diameter: Horizontal wire: 4.0mm; Vertical wire: 4.0mm.
Mesh apertures: 76.2mm × 12.7mm.
Panel height: from 1.27meter to 5.2meter.
Panel width: 25 × 15mm.
Post size: 60 × 60 × 2.5mm, 80 × 80 × 2.5mm, 100 × 100 × 3/4mm, 120 × 120 × 5mm.
Post height: from 1500mm to 6200mm.
Finish:
  • Hot dipped galvanized 300g/sm or 42micron.
  • Powder coated to BS EN 13438.
Specification:
358 Mesh Panels
Posts
Fence
Panel Size
Section
O/A Length
Total number of fixings
height m
Height/Width mm
Inters- 1 Clamp bar
Corners- 2 Clamp bars
1.27
1270 × 2515
60x60x2.5mm
1500
4
8
1.80
1800 × 2515
60x60x2.5mm
2300
6
12
2.0
2007 × 2515
60x60x2.5mm
2700
7
14
2.4
2400 × 2515
60x60x2.5mm
3100
9
18
3.0
2997 × 2515
80x80x2.5mm
3800
11
22
3.3
3302 × 2515
80x80x2.5mm
4200
12
24
3.6
3607 × 2515
100x100x3mm
4500
15
26
4.2
4204 × 2515
100x100x4mm
5200
15
30
4.5
4496 × 2515
100x100x5mm
5500
16
32
5.2
5207 × 2515
120x120x5mm
6200
18
36
Installation:
Clamp and M8 bolt.
Use clamp and M8 square bolts with nuts through posts.
Top barbed wire: Muyuan 358 mesh can supply top razor wire or barbed wire for further security.
Gate: Muyuan can design and make gates that suit to 358 fence with anti-climb protection.
Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm


Buy cheap Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm product

Anti Cut 358 Mesh Fence 12.70mm*76.20mm*3.00mm Images
